UNPRECEDENTED PERFORMANCE
Unparalleled Performance on VirtuallyEvery Barcode in Any Condition
Only the DS8100 Series combines the power of an 800 MHz microprocessor, a high-resolution megapixel sensor and Zebra’s exclusive PRZM technology. With this unique combination of hardware and advanced algorithms, the DS8100 Series instantly captures the most problem aticbarcodes -including dense, poorly printed, crinkled, faded, distorted, dirty or damaged, as well as electronic barcodeson dimly lit displays.
Superior Scan Range
A scanning range up to 24 in./61 cm,a high resolution imaging sensor and abright “aiming spot” improve checkout speed. Now, cashiers in busy checkou tenvironments can easily scan items ina customer’s shopping cart – without leaving the cash-wrap.
Power to Scan Continuouslyfor 24 Hours
No matter how busy your store is, withZebra’s exclusive PowerPrecision+ smartbattery in the cordless DS8178, your workers will always have the power they need for the busiest shift. Your devices are always available – no need for charging during the business day.
INNOVATION BEYOND THE BARCODE
PRZM Intelligent lmaging
Only from Zebra, PRZM features reset the bar for imaging performance. Poor images are turned into instantly useful images for faster decoding. PRZM then handles some of the processing typically handled in the decoder to reduce power usage, improve battery cycle times and further increase decoding speed.
Support for the Barcode ofthe Future – Digimarc
The DS8100 Series supports Digimarcdigital water mark technology, which enables a barcode to be printed repeatedly over all surfaces of a product like wallpaper . yet remain completelyinvisible to the naked eye. Cashiers nolonger need to locate and position abarcode in the field of view of the imager.enabling faster checkout and easier self-checkout.
Capture Multiple Barcodes withOne Press of the Scan Trigger
Multi-code Data Formatting (MDF)provides the ability to capture multiple barcodes and transmit only those required in the precise order the application requires.
Exclusive Battery Charge Gauge
No more guess work on the status of a battery at the startof a shift The DS8178 is the only scanner in its class that makes it easy to see at a glance whether a battery needsto be replaced before the scanner is placed into service.
Eliminate Bluetooth Interference withZebra’s Proprietary Wi-Fi Friendly Mode
Ensure that your DS8178 Bluetooth scanners only operate on channels that are not shared with your wireless LAN (WLAN), protecting WLAN service levels for your workers and your customers.
Instantly Capture Full Page Documents
The DS8100 Series is the only device in its class that can capture a full page document. With a single press ofthe scan trigger, Zebra’s Intelligent Document Capture and the high-resolution 1280 x 960 camera work together to capture a high-resolution image of a full page8.5 x 11 or A4 document, and transmit the data in the right format for electronic storage – eliminating the cost and space requirements for a document scanner.
Capture Drivers License DataDL version required
With one press of the scan trigger, cashiers can capture and parse data on drivers licenses to automatically populate a loyalty or credit card application, verify agefor age-restricted purchases and more.
Direct Decode Indicator Improves Productivity
Since the illumination on the barcode flashes to indicatea good decode, workers never need to pause to makesure a barcode was captured correctly.
