Resets the bar for versatility and performance
Capture it all from direct part marks to extra-wide barcodes
No matter what type of marks and barcodes are found in your manufacturing operations, you can capture them all with theDS4608-DPE. It easily reads the tiny and dense laser etchedDPM codes on plastic and metal subcomponents, as well as ink mark, chemical etch, ink jet mold and thermal spray. And the same imager can read 4-inch wide barcodes found on picklists.carton labels and packages, delivering outstanding value-youc an use the same device for multiple applications throughout your operations
Count on great performance to keep your production line moving
What makes the DS4608-DPE unique lts patented rear enginedesign creates more room for a built-in diffuser providing optimal illumination on a wide variety of surfaces. Indirect lighting enables the capture of marks printed on shiny and reflective surfaces, while direct light provides the bright light needed to successfully read low contrast barcodes and laser-etched marks. And the 800 MHz microprocessor,megapixel sensor and Zebra’s exclusive PRZM Intelligent lmaging technology further improve performance on challenging barcodes The result High-confidence scanning for fewer exceptions and workflow disruptions.
Capturing high density barcodes is easier than ever
Direct part marks and high density barcodes can be tough to scan,but not with the DS4608-DPE. This intuitive imager has the widest decode range in its class-enabling workers to position it at a more natural distance to see the barcode they are scanning. The result ispoint and shoot simplicity for some ofthe most challenging barcodes.
Haptic and visual feedback ideal for noisy production lines
On the production line, the traditional beep tone can be hard to hear That’s why the DS4608-DPE offers multiple feedback modes:haptic/vibration, a good decode LED that’s visible from any position.a traditional beep tone, plus Zebra’s Direct Decode Indicator that projects the illumination on the barcode. No matter how noisy your environment might be, workers instantly know they are about to utilize the right component there’s no need to stop and verify that a scan was completed.
Day-in, day-out dependability on the production line
Your production line doesn’t stop, and neither does the DS4608-DPElt’s engineered for durability, inside and out. IP52 sealing protects against spills, while a patented double-sealed optical system protectsthe critical optical components from dust and liquid-ensuring that theeye’ of the scanner always captures the sharpest possible barcode image for fast and reliable decoding. The recessed scan window protects against smudges, dirt and scratches, which can impact performance. And the scanner is built to survive multiple 6 ft./1.8 m drops to concrete and 2,000 tumbles in our punishing tumble test
On-the-fly switching between handheld and hands-free scanning
Simply place the DS4608-DPE in its presentation stand to automatically switch to hands-free mode-no change of settings is required.
Do more with productivity-enhancing innovation
Capture multiple barcodes with one press of the scan trigger
With Multi-Code Data Formatting (MDF) the DS4608-DPE can scan multiple barcodes with a single trigger pull and transmit only the barcodes you need, in the order your application expects. You get superior versatility and value-the same imager that can read small dense codes on the production line can also read multiplepaper codes on packages in the receiving area.
Single out one barcode from many
With Zebra’s Preferred Symbol, the DS4608-DPE can capture andoutput only the preferred barcode, so workers no longer have towaste time physically covering nearby barcodes before scanning
Industry-preferred management tools
Effortless deployment
The DS4608-DPE couldn’t be easier to setup. Right out of the box the imager is configured for the applications you use every day,while auto-host detect cables automatically select the right hostinterface_just plug in the scanner and you’re ready to go.
Easily deploy and manage all of your imagers
123Scan, a complimentary DataCapture DNA tool, is intuitive enough for first-time users. You can easily create configuration barcodesto program imagers, update firmware or stage a large number of devices. lf your imagers are in multiple locations across the count your around the world, you can use the complimentary Scanner Management Service (SMS) to configure and update the firmware or any DS4608-DPE device that is plugged into a host. No depot standing or user action is required such as the scanning of aconfiguration barcode.
DataCapture DNA-transforming scanners from the inside
Simplify the entire scanning experience
Hardware is just the start of what you need to maximize the value of your scanners. The DS4600 Series is powered by DataCapture DNA a set of unique development, management, visibility and productivity tools. Leveraging Zebra’s 50 years of innovation, DataCapture DNAturns Zebra scanners into powerful tools that lower your TCO and help workers get more done each day. Decrease development cycles with development tools. Dramatically simplify scanner deployments of any size with management tools. Get the remote analytics you needto keep scanners up and running with visibility tools. And reach new levels of productivity with innovations that streamline tasks.
