Meet your everyday scanning needs
The DS1001 offers practical barcode scanning performance so workers can easily capture your everyday 1D and 2D barcodes.With omni-directional scanning, there is no need to line up the imager and the barcode for true point-and-shoot simplicity.
Streamline your recordkeeping and meet government mandates
Whether you need to scan the barcode on an invoice or a QR code on a mobile device, the DS1000 has you covered. Easy to setup and always reliable, you can count on the DS1000 to help you meet your record keeping needs.
Simplify the scanning experience with DataCapture DNA
It takes more than hardware to resolve today’s toughest enterprise challenges. It requires intelligent software to address the needs of every stakeholder. That’s why Zebra scanners contain Data Capture DNA, the genetic code that simplifies the entire scanning experience. Every DS1000 comes with complimentary management tools like the industry’s most intuitive configuration wizard, so even a first-time user can easily setup the scanner. Additionally, set-it-and-forget-it remote management tools dramatically simplify scanner deployments of any size. And our Scanner Software Development Kit (SDK) provides everything you need, including documentation, drivers, test utilities and sample source code for Windows, Android, iOS and Linux.
Proven quality you can trust
For over 40 years, Zebra has set new standards in the scanning industry, providing cutting-edge technology and products across all industries and businesses. It’s why 95% of Fortune 500 companies trust Zebra to reach higher levels of productivity, growth and service. When you choose the DS1000, you get the peace of mind that comes with choosing world-renowned quality and reliability, as well as well-proven technology from the global leader in handheld barcode scanning.
PHYSICAL CHARACTERISTICS
Dimensions 6.5 in. H x 2.6 in. W x 3.9 in. D 16.5 cm H x 6.6 cm W x 9.8 cm D
Weight 4.69 oz. / 133.0 g
Input Voltage Range 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
Current Operating Current at Nominal Voltage (5.0V):200 mA (typical). (Note: Auto-Aim and Illumination on Acquiring Image)Standby Current (idle) at Nominal Voltage (5.0V):150 mA (typical). (Note: Auto-Aim On)
Color Midnight Black
Supported Host Interfaces USB
User Indicators Direct Decode Indicator; good decode LEDs; Rear view LEDs; beeper (adjustable tone and volume)
PERFORMANCE CHARACTERISTICS
Motion Tolerance (Handheld) Up to 5 in./13 cm per second for 13 mil UPC
Swipe Speed (Hands-Free) Up to 30.0 in./76.2 cm per second for 13 mil UPC
Light Source Aiming Pattern: Linear 624 nm Amber LED
Illumination 645 nm Super-Red LED
Imager Field of View 32.8° H x 24.8° V Nominal
Image Sensor 640 x 480 pixels
Minimum Print Contrast 25% minimum reflective difference
Skew/Pitch/Roll Tolerance +/- 65°; +/- 65°; 0-360°
Minimum Element Resolution Code 39 – 4.0 mil; Code 128 – 4.0 mil;Data Matrix – 6.0 mil; QR Code – 6.7 mil
USER ENVIRONMENT
Operating Temperature 32.0° to 122.0° F/0.0° to 50.0° C
Storage Temperature -40.0° to 158.0° F/-40.0° to 70.0° C
Humidity 5% to 95% RH, non-condensing
Drop Specification Designed to withstand multiple drops at4.0 ft./1.2 m to concrete
Tumble Specification Designed to withstand 250 tumblesin 1.5 ft./.5 m tumbler1
Environmental Sealing IP40
Electrostatic Discharge (ESD) ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct,+/-8 KV Indirect
Ambient Light Immunity 0 to 10,000 Foot Candles/0 to 107,600 Lux
REGULATORY
Electrical Safety EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07
Environmental RoHS EN 50581
LED Safety IEC 62471
IT Emissions EN 55032 (Class B)
IT Immunity EN 55024
Harmonic Current Emissions EN 61000-3-2
Voltage Fluctuation and Flicker EN 61000-3-3
Radio Frequency Devices 47 CFR Part 15, Subpart B, Class B
Digital Apparatus ICES-003 Issue 6, Class B
DECODE CAPABILITIES2
1D Code 39, Code 128, Code 93, Codabar/NW7, Code 11,MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1DataBar, Base 32 (Italian Pharma)
2D PDF417, Composite Codes, TLC-39, Aztec, DataMatrix,MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes
WARRANTY
Subject to the terms of Zebra’s hardware warranty statement, the DS1000 Corded Scanner is warranted against defects in workmanship and materials for twelve (12) months from the date of shipment. For the complete Zebra hardware product warranty statement, go to: http://www.zebra.com/warranty
